Axial piston fixed pump A10FZO series 10
Цену уточняйте
Минимальная сумма заказа на сайте — 20 руб
- Под заказ
Отправка с 04 июня 2024Под заказ
Цену уточняйте
Axial piston fixed pump A10FZO series 10+375 (29) 192-99-90
- +375 (23) 229-20-00
- +375 (29) 118-18-01
- +375 (29) 122-10-99
Description
- Suitable for variable-speed operation with synchronous and asynchronous motors
- Size 6 … 63
- Nominal pressure 315 bar
- Maximum pressure 350 bar
- Open circuit
Features
- For use in single- and double-quadrant operation
- Suitable for start/stop-operation
- Suitable for long pressure retention operation
- Well-tried A10 rotary group technology
- Through drive possibility
- High total efficiency
- Swashplate design
Technical data
Table of values
|
Size |
6 | 8 | 10 | 11 | 14 | 16 | 18 | 21 | 23 | 28 | 37 | 45 | 58 | 63 | |||
|
Displacement |
Vg |
cm³ |
6 | 8.1 | 10.6 | ||||||||||||
|
Nominal pressure |
pnom |
bar |
315 | 315 | 315 | 315 | 315 | 315 | 315 | 315 | 315 | 315 | 315 | 315 | 315 | 315 | |
|
Maximum pressure |
pmax |
bar |
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
|
Maximum speed 1) |
nnom |
rpm |
3600 | 3600 | 3600 | ||||||||||||
|
Flow |
at nnom |
qV |
l/min |
21.6 | 29 | 38.2 | |||||||||||
|
Power |
at nnom and pnom |
P |
kW |
11.3 | 15.3 | 20 | |||||||||||
|
Torque |
at pnom |
M |
Nm |
30 | 40.5 | 53 | |||||||||||
|
Weight (approx.) |
m |
kg |
8.4 | 8.4 | 8.4 | ||||||||||||
Информация для заказа
- Цена: Цену уточняйте
